Roll-Belt 150 SuperFeed™ Diameter Min. / Max. (cm) 90 / 150 Width (cm) 120

THE FASTEST WAY TO CLEAR FIELDS

The pick-up is perhaps one of the most important parts of your Roll-Belt baler. New Holland has completely redesigned the 2.3 metre wide pick-up to boost capacity by up to 20%. If that wasn’t enough, state-of-the-art baling technology ensures uniform flow for non-stop, high capacity baling

OUTSTANDING CAPACITY Think variable chamber productivity. Think New Holland Roll-Belt baler. Capacity has been increased by up to 20% thanks to the redesigned pick-up.

BALE QUALITY The Roll-Belt guarantees top drawer bale quality. Always. An all-new moisture sensing system, which uses two discs on either side of the bale chamber to calculate average moisture, enables operators to respond, in real time, to changing baling conditions.

EASE OF OWNERSHIP The Roll-Belt baler belongs in the field, and efficient servicing and maintenance means your baler will spend more time in the field, earning its keep, as opposed to being kept.

ABSOLUTE BALING PLEASURE Operators will relish long baling days as the Roll-Belt baler has been designed with them in mind

Roll-Belt 150 Super Feed	Roll-Belt 150 Super Feed	Roll-Belt 150 Super Feed	Roll-Belt 150 Super Feed
Bale dimensions
Diameter Min. / Max. (cm)	90 / 150	90 / 150	90 / 150
Width (cm)	120	120	120
Tractor requirements
Minimum PTO power [kW/hp(CV)]	52/70	75/100	52/70
PTO speed standard / optional (rpm)	540 / 1000	540 / 1000	540 / 1000
Hydraulic remotes Min. / Max.	2 / 4	2 / 4	2 / 4
Main drive
Gearbox	Enclosed oil immersed	Enclosed oil immersed	Enclosed oil immersed
Protection	Cut-out clutch	Cut-out clutch	Cut-out clutch
Pick-up
Standard working width standard / optional (m)	2 / 2.3	2 / 2.3	2 / 2.3
Five tine bar pick-up with rubber tines	Standard	Standard	Standard
Roller windguard	Standard	Standard	Standard
Feed assist auger	Optional	Optional	Optional
Flotation	Adjustable spring	Adjustable spring	Adjustable spring
Hydraulic pick-up lift	Standard	Standard	Standard
Pick up protection	Cut-out clutch	Cut-out clutch	Cut-out clutch
No tools folding pickup gauge wheels	Standard	Standard	Standard
No tools folding castoring pickup gauge wheels	Optional	Optional	Optional
Gauge wheels (15×6.00-6)	Standard	Standard	Standard
Feeding system
Feeder	Rotor width 455mm ’W’ tine configuration	Rotor width 455mm ’W’ tine configuration	Rotor width 455mm ’W’ tine configuration
Drop floor	Optional	Standard	Optional
CropCutter™ system	–	Standard	–
Knives options	–	15	–
Knife distance (mm)	–	65	–
Knife activation, in – out	–	Hydraulic	–
Knife protection	–	Individual spring	–
Bale formation
Type	Roll-Belt™ technology (Combination of rollers and belts)	Roll-Belt™ technology (Combination of rollers and belts)	Roll-Belt™ technology (Combination of rollers and belts)
Pivoting formation rolls	3	3	3
Belts	Four 273mm endless	Four 273mm endless	Four 273mm endless
Bale shape indicators	Standard	Standard	Standard
Tying system
Net only	Standard	Standard	Standard
Net wrapping system	Duckbill	Duckbill	Duckbill
Net storage	3 Standard	3 Standard	3 Standard
Net coverage	EdgeWrap™	EdgeWrap™	EdgeWrap™
Bale density system
Dual density system	Standard	Standard	Standard
Density control	In-cab control through monitor	In-cab control through monitor	In-cab control through monitor
Electronic control system
Bale Command™ Plus II monitor	Standard	Standard	Standard
ISO 11783 connection ready	Optional	Optional	Optional
IntelliView™ IV monitor	Optional	Optional	Optional
IntelliBale™ system	Optional	Optional	Optional
Real time bale moisture sensor	Optional	Optional	Optional
Electronic safety cut out	Standard	Standard	Standard
Brakes
Hydraulic	Optional	Optional	Optional
Pneumatic	Optional	Optional	Optional
Maximum travelling speeds
Maximum travelling speeds	50kph	50kph	50kph
Bale ramp
Bale ramp	Standard	Standard	Standard
Servicing
Servicing	In-cab control through monitor	In-cab control through monitor	In-cab control through monitor
Baler dimensions
Length (m)	4.475	4.475	4.475
Width / Height on 380/55-17 tyres (m)	2.415 / 2.79	2.415 / 2.79	2.415 / 2.79
Width / Height on 480/45-17 tyres (m)	2.61 / 2.83	2.61 / 2.83	2.61 / 2.83
Width / Height on 500/55-20 tyres (m)	2.85 / 2.76	2.85 / 2.76	2.85 / 2.76
Weight
Weight (Max.) (kg)	3715	3715	3715
