RIGHT FOR YOUR FARM The T7 range was developed following intensive consultations with New Holland customers including contractors, arable and cash crop farmers.
READY TO TURN YOUR NEEDS INTO NEW FEATURES New Holland engineers represent one of the best design teams in the world.
TESTING DURING DEVELOPMENT Try and test. Then try and test again. Every T7 tractor undergoes severe and comprehensive tests during both the development and production processes, in order to deliver you the perfect working partner.
T7 RANGE: FOURTEEN MODELS. THREE TRANSMISSIONS. COUNTLESS AWARDS. The T7 long wheelbase is part of the extended T7 family which means there is a New Holland T7 tractor to match all of your specific business needs.
SIX MODELS RIGHT FOR YOUR FARM
The T7 range was developed following intensive consultations with New Holland customers including contractors, arable and cash crop farmers. The aim was to produce a completely restyled tractor with improved functionality, while adhering to the even stricter Stage V emissions regulations. These improvements have made the T7 a true icon of tractor design, brimming with state-of-the-art technology, innovation, power and efficiency.
POWERED BY FPT INDUSTRIAL
New Holland is not going it alone when it comes to Stage V technology. They can draw on the experience of their in-house engine development group: FPT Industrial.
Pioneers: Fiat invented Common Rail technology in the 1980s and brought it to the masses in 1997 on the Alfa Romeo 156. They were the very first to introduce it on agricultural machines on the TS-A tractor. Pioneering. Always.
Cleaner: For the eleventh consecutive year, CNH Industrial has topped the Dow Jones Sustainability World and Europe indexes for the Industrial Engineering sector. Cleaner. Everywhere.
Proven: FPT Industrial has pioneered SCR technology since 1995 and has already produced more than 2.5 million SCR systems during the last fifteen years for the agricultural, construction and trucking industry. The award-winning HI-eSCR solution has been extensively tested and has been fitted in the T7 range since 2015. Reliability. Confirmed.
Pioneers: Fiat invented Common Rail technology in the 1980s and brought it to the masses in 1997 on the Alfa Romeo 156. They were the very first to introduce it on agricultural machines on the TS-A tractor. Pioneering. Always.
Cleaner: For the eleventh consecutive year, CNH Industrial has topped the Dow Jones Sustainability World and Europe indexes for the Industrial Engineering sector. Cleaner. Everywhere.
Proven: FPT Industrial has pioneered SCR technology since 1995 and has already produced more than 2.5 million SCR systems during the last fifteen years for the agricultural, construction and trucking industry. The award-winning HI-eSCR solution has been extensively tested and has been fitted in the T7 range since 2015. Reliability. Confirmed.
Technical specifications
|
T7.245
|
T7.245
|
||||
|---|---|---|---|---|---|
New Holland engine* |
|||||
|
New Holland engine*
|
Nef
|
Nef
|
|||
|
No. of cylinders / Aspiration / Valves
|
6 / T / 4
|
6 / T / 4
|
|||
|
Stage V ECOBlue™ HI-eSCR 2 system (Selective Catalytic Reduction)
|
Standard
|
Standard
|
|||
|
Approved for HVO / Biodiesel blend**
|
Standard / B7
|
Standard / B7
|
|||
|
Capacity (cm³)
|
Standard
|
6728
|
|||
|
Max. horsepower – ISO TR14396 – ECE R120 [kW/hp(CV)]
|
147/200
|
162/220
|
|||
|
Max. EPM horsepower – ISO TR14396 – ECE R120 [kW/hp(CV)]
|
165/225
|
180/245
|
|||
|
Rated engine speed (rpm)
|
2200
|
2200
|
|||
|
Max. EPM torque – ISO TR14396 (Nm@rpm)
|
940@1500
|
1035@1500
|
|||
|
Reversible fan
|
Optional
|
Optional
|
|||
|
Exhaust brake
|
Optional
|
Optional
|
|||
|
Diesel tank capacity (Litres)
|
465
|
465
|
|||
|
AdBlue tank capacity (Litres)
|
54
|
54
|
|||
|
Service interval (hours)
|
750
|
750
|
|||
Auto Command™ Continuously Variable Transmission |
|||||
|
Preset and Custom transmission aggressiveness settings
|
Standard
|
Standard
|
|||
|
Active StopStart function
|
Standard
|
Standard
|
|||
|
Force base propulsion control
|
Standard
|
Standard
|
|||
|
Auto Command™ Continuously Variable Transmission (40kph ECO)
|
Standard
|
Standard
|
|||
|
Min. speed / Max. speed (kph)
|
0.03 / 40 @ 1300rpm
|
0.03 / 40 @ 1300rpm
|
|||
|
Auto Command™ Continuously Variable Transmission (50kph ECO)
|
Optional
|
Optional
|
|||
|
Min. speed / Max. speed (kph)
|
0.03 / 50 @ 1600rpm
|
0.03 / 50 @ 1600rpm
|
|||
Axles |
|||||
|
4WD front axle (Standard/ High Capacity***)
|
Standard / Optional
|
Standard / Optional
|
|||
|
Terraglide™ front axle suspension
|
Standard
|
Standard
|
|||
|
Steering angle (°)
|
55
|
Standard
|
|||
|
CustomSteer™ system
|
Optional
|
Optional
|
|||
|
Rear axle (Standard/ High Capacity***)
|
Standard / –
|
Standard / –
|
|||
|
Turning radius (mm)
|
6100
|
6100
|
|||
Hydraulics |
|||||
|
Closed Centre Load Sensing (CCLS)
|
Standard
|
Standard
|
|||
|
Auto Command – Main pump flow Standard / MegaFlow™ option
|
150 / 170
|
150 / 170
|
|||
Remote valves |
|||||
|
Max. no. rear valves (140 lpm max flow per valve)
|
5
|
5
|
|||
|
Advanced configurable joystick control
|
Optional
|
Optional
|
|||
|
Max. no. mid mount valves
|
3
|
3
|
|||
|
Customisable remote configuration
|
Standard
|
Standard
|
|||
Linkage |
|||||
|
Max. lift capacity at ball ends (kg)
|
10464
|
10464
|
|||
|
Front linkage max lift capacity at ball ends (kg)
|
5925
|
5925
|
|||
PTO |
|||||
|
Rear PTO engine speed at 540 / 540E / 1000 / 1000E (rpm)
|
1931 / 1598 / 1912 / 1583
|
1931 / 1598 / 1912 / 1583
|
|||
|
Auto PTO management
|
Standard
|
Standard
|
|||
|
Front PTO (1000rpm)
|
Optional
|
Optional
|
|||
Brakes |
|||||
|
Hydraulic Trailer Brakes
|
Optional
|
Optional
|
|||
|
Pneumatic Trailer Braking System
|
Optional
|
Optional
|
|||
|
Intelligent Trailer Brake system
|
Optional
|
Optional
|
|||
Cab |
|||||
|
Four pillar 360° Horizon™ Ultra cab with FOPS – OECD code 10 level 1
|
Standard
|
Standard
|
|||
|
Horizon™ Ultra cab category level – EN 15695
|
2
|
2
|
|||
|
Cab noise level – 77/311EEC [dB(A)]
|
66
|
66
|
|||
|
Heated front and rear windscreen
|
Optional
|
Optional
|
|||
|
Roof LED light packs – standard / option
|
8/14/2024
|
8/14/2024
|
|||
|
Belt and Hood lighting packs – standard / option
|
4/8/2010
|
4/8/2010
|
|||
|
LED road driving lights
|
Optional
|
Optional
|
|||
|
Cab suspension – Comfort Ride™ / Semi active Comfort Ride™
|
Standard / Optional
|
Standard / Optional
|
|||
|
Comfort seat
|
Standard
|
Standard
|
|||
|
Dynamic Comfort™ heated seat, carpet, leather steering wheel
|
Optional
|
Optional
|
|||
|
Auto Comfort™ Active Climate Control, carpet, leather steering wheel
|
Optional
|
Optional
|
|||
|
Blue Power Package: Metallic Blue and Silver paint, branded seats and carpet
|
Optional
|
Optional
|
|||
|
Instructors seat with seat belt
|
Standard
|
Standard
|
|||
|
170° front hood mounted and cab pillar rear facing cameras
|
Optional
|
Optional
|
|||
|
Wireless camera
|
Optional
|
Optional
|
|||
|
Front wiper swept angle 120° / 240°
|
Standard / Optional
|
Standard / Optional
|
|||
|
Electronic adjustable heated mirrors with wide angle lens
|
Standard
|
Standard
|
|||
|
Electrically extendable mirror arms
|
Optional
|
Optional
|
|||
|
Remote locking and immobiliser
|
Optional
|
Optional
|
|||
|
Push button engine start/stop
|
Optional
|
Optional
|
|||
|
Auto climate control with zone Control
|
Standard
|
Standard
|
|||
|
Integrated cab storage solutions
|
Standard
|
Standard
|
|||
|
Cooled compartment
|
Optional
|
Optional
|
|||
|
DAB Radio with Bluetooth and integrated phone microphone
|
Optional
|
Optional
|
|||
|
Standard power ports / Optional AC power outlet and additional USB
|
Standard / Optional
|
Standard / Optional
|
|||
|
Fender external controls Remote valve / Engine control functions
|
Optional / Optional
|
Optional / Optional
|
|||
|
External air line connection (pneumatic brakes required)
|
Optional
|
Optional
|
|||
|
High capacity air compressor (pneumatic brakes required)
|
Optional
|
Optional
|
|||
|
Large portable coolbox (Dealer installed)
|
Optional
|
Optional
|
|||
|
LED beacons (1 / 2)
|
Optional
|
Optional
|
|||
PLM Intelligence™ system |
|||||
|
SideWinder™ Ultra armrest
|
Standard
|
Standard
|
|||
|
CommandGrip™ handle
|
Standard
|
Standard
|
|||
|
IntelliView™ 12 colour monitor
|
Standard
|
Standard
|
|||
|
IntelliSteer® guidance ready
|
Standard
|
Standard
|
|||
|
PLM® Cygnus receiver (PLM 1, PLM 2, PLM 3 & PLM RTK / PLM RTK+)
|
Optional
|
Optional
|
|||
|
Headland Turn Sequencing HTS / HTS II
|
Standard / Optional
|
Standard / Optional
|
|||
|
IntelliTurn™ with Headland Turn Sequencing II (HTS II) system
|
Optional
|
Optional
|
|||
|
ISOBUS II / III and TIM
|
Standard / Optional
|
Standard / Optional
|
|||
|
IntelliField™ boundary, map & guidance line data inter-vehicle sharing
|
Optional
|
Optional
|
|||
|
New Holland FieldOps™ Professional telematics (5 years subscription free)
|
Standard
|
Standard
|
|||
Uptime Solutions – Training & Support Systems |
|||||
|
New Holland Remote Assistance (1st years subscription free)
|
Standard
|
Standard
|
|||
|
IntelliView™ Connect remote display
|
Standard
|
Standard
|
|||
|
New Holland Breakdown Assist
|
Standard
|
Standard
|
|||
Weights |
|||||
|
Unballasted weights (kg)
|
8000 / 8400
|
8000 / 8400
|
|||
|
Max. permissible weight (kg)
|
14400
|
14400
|
|||
