- 6 Tine Tiller Designed for 18 – 50 HP at the PTO for tractors.
- Heavy Duty Rotary Tiller Designed for Tilling & Breaking up to 500 acres per year
- Oil-Bath heavy duty 1-1/4” thick side gears combined weight 30 lbs
- Inward facing outer tines for definite tilled edge
- 1-3/8” 6-spline slip clutch driveline included
- Heavy replaceable 28 oz. tines
- Cat I & Cat II 3-point hitch models
- Adjustable tilling depth up to 8”
- 1/4” Double walled housing
- 65 hp rated gearbox
- 18” blade swing
Specifications:
| Model Number | FH-IGN105 |
| Standard Tine Rotation | Yes |
| Tilling Width | 41” |
| Right Offset | 3” |
| Overall Width | 50 1/2” |
| Min – Max Tractor HP | 18 – 50 HP |
| 3Pt. Hitch | Cat. I |
| Gear Box Rating | 65 HP |
| Number of L shaped Tines | 24 |
| Drive Type | Gear to Gear |
| Double Walled Housing | 1/4” |
| Rotor Swing Dia. | 18” |
| Adjustable Tilling Depth | 2” – 8” |
| Driveline Type 540 PTO | Series 4 1-3/8” SPL w/QD 1-3/8” SPL w/Slip Clutch |
| Weight | 620 lbs |
| Crated Weight | 640 lb |
