| Max. operating mass | 7,500 lbs |
|---|---|
| Operating mass (incl. ROPS) | 5,700 lbs |
| Module mass (front/rear) | 2,700 lbs/ 3,000 lbs |
| Traction | |
| Speed range | 0-6 mph |
| Vertical oscillation | ±10° |
| Max. theoretical gradeability | 42 % |
| Compaction | |
| Centrifugal force | 7,600/ 6,500 lb |
| Nominal amplitude | 0.020 in |
| Static linear load (front/rear) | 58 / 64 lbs/in |
| Vibration frequency | 3,960/ 3,660 vpm |
| Water tank | 54 gal |
| Engine | |
| Manufacturer/Model | Kubota D1703-M (IIIA) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 26 kW (35 hp) @ 2800 rpm |
| Fuel tank capacity | 12 gal |
| Alternative Engine | |
| Manufacturer/Model | Kubota D1703-DI (T4/V) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 18.5 kW (25 hp) @ 2200 rpm |
| Alternative Engine | |
| Manufacturer/Model | Kubota D1803-CR (T4/V) |
| Type | Water cooled diesel engine |
| Rated power, SAE J1995 | 28 kW (37,5 hp) @ 2700 rpm |
| Hydraulic system | |
| Driving | Axial piston pump with variable displacement. Radial piston motors (2) with constant displacement. |
| Vibration | Gear pump/motors with constant displacement. |
| Steering | Gear pump with constant displacem. |
| Service brake | Hydrostatic in forward and reverse lever. |
| Parking/Emergency brake | Failsafe multidisc brake in both drums. |
-
