new holland T7040

T7040– COMMANDING POSITION

New Holland has spent over five years developing the Series T7040 tractor range. Exhaustive testing has been carried out in the main European countries and the USA. The result is a range of tractors ideally matched to the changing needs of modern agriculture. They are lighter but more powerful, stronger but more manoeuvrable and economical. Series T7040 are tractors that can efficiently use precious fuel. They have brilliant ergonomics for ease of operation. In-cab noise levels are so low that they set new standards. Dependability is a key T7040 strength. The depth of development devoted to Series T7040 exceeds that of any tractor yet produced by New Holland. Modern manufacturing techniques have been implemented, helping ensure strict quality standards are maintained throughout the tractor’s production. Random 40 hour shakedown tests are carried out on tractors leaving the line and before it leaves the factory, every tractor will have been through no fewer than 600 performance checks.

The new standard in the 160 to 240hp(CV) segment New Holland is a tractor specialist, with unrivalled expertise in producing tractors to match modern agricultural needs. Agriculture is always evolving and T7040 tractors have been developed to offer all the versatility modern farming demands. Whatever your needs a T7040 tractor can be specified to match them.

Contractor-focussed dependability

Series T7040 tractors offer the right mix of power and size to ensure they will find work in a wide range of operations; from baling and demanding PTO work through both light and heavy cultivation. Series T7040 tractors have the benefit of a Power Boost in transport too. This versatility ideally suits contractor’s operations. From the outset, ease of maintenance and low whole-life operating costs have been a priority. Their close monitoring has been ongoing over thousands of hours. In-house testing remains part of New Holland’s commitment to excellence. Series T7040. Dependable performance you can rely on.

Engine (*)
No of cylinders / Aspiration / Valves / Emission level	6 / TI / 4 / Tier III
Fuel injection system high pressure Common Rail
Capacity (cm³)	6728
Bore x stroke (mm)	104 x 132
Rated power – ISO 14396 – ECE R120 [kW/hp(CV)]	134/182
Rated power – ISO 14396 – ECE R120 – Engine Power Management [kW/hp(CV)]	160/218
Max.power – ISO 14396 – ECE R120 [kW/hp(CV)]	147/200
Max.power – ISO 14396 – ECE R120 – Engine Power Management [kW/hp(CV)]	173/234
Rated engine speed (rpm)	2200
Max. torque – ISO 14396 – ECE R120 at 1400rpm (Nm)	844
Max. torque – ISO 14396 – ECE R120 at 1600rpm – Engine Power Management (Nm)	938
Torque rise standard / with Power Management (%)	45 / 35
Fuel tank capacity (l)	410

Power Command™ full powershift 40 / 40E / 50kph
Powershuttle and IntelliShift™ transmission management
No of speeds 40kph (F x R)	18 x 6
No of speeds 40kph Eco or 50kph (F x R)	19 x 6
Minimum creep speed (m/h) at rated speed (m/h)	225

Axles
4WD front axle
SuperSteer™ front axle
Terraglide II™ active front axle suspension
Steering angle Standard / Terraglide II™ / SuperSteer™ axle (°)	55 / 55 / 65

Hydraulics
CCLS Closed Centre Load Sensing
Main pump flow Standard / MegaFlow™ (l/min)	120 / 150
Steering pump flow (l/min)	66.5
Electronic Draft Control
Max. lift capacity rear linkage (at ball end) (kg)	8647
Max. lift capacity front linkage Standard / Terraglide II™ / SuperSteer™ axle (at ball end) (kg)	3620 / 3620 / 2730

Standard  Optional
T704
Engin
Power Command™ full powershift 40 / 40E / 50kph
Axles
Hydraulics
Remote valves
PTO Electro-Hydraulic, 540/1000 or 540E/1000
PTO Electro-Hydraulic, 540/1000 or 540E/1000
Engine speed at 540 / 540E / 1000rpm (rpm)	1950 / 1550 / 2178
Automatic soft start
Fender mounted switch and configurable Auto PTO

Cab
Air Suspension Seat
Auto Comfort™ Active seat
Air conditioning
Automatic climate control / electric mirrors / hi-fi upgrade
Comfort Ride™ two stage suspension
Performance monitor with ISO 11786 connector
Intelliview II colour monitor with ISO 11783 connector
Optimum cab noise level EC 77/311 (dB(A))	69.6
